| Place of Origin: | China |
| Brand Name: | Junqi |
| Certification: | CE,ROHS, UL |
| Model Number: | JQM-13SS050 |
| Minimum Order Quantity: | 50pcs |
|---|---|
| Price: | USD3-usd5/pc (Negotiable) |
| Packaging Details: | suite for export |
| Delivery Time: | as confirmed |
| Payment Terms: | L/C, T/T, Western Union,PAYPAL |
| Supply Ability: | 10000PCS/Month |
| Product Name: | DC Gear Motor | Model: | JQM-13SS050 |
|---|---|---|---|
| Voltage: | 3V/6V/9v/12V | Speed: | 20~1000RPM |
| Torque: | 1~5kgf.cm | Normal Shaft Length: | 4.4mm,6mm,8mm,10mm |
| Shaft Diameter: | 3mm | Application: | BOAT, Car, Electric Bicycle, FAN, Home Appliance |
1. Main voltage: 3VDC
2. Typical applications: Automatic door-lock,projector,hairdressing equipment
3. Square Gearbox size:12mm*13mm*L
4. Torque: 20gf.cm~2500gf.cm
5. Direction:CW, CCW
6. Voltage, speed, and shaft can be customized based
7. Encoder 3PPR available
Driving Motor Data:
| Motor model |
Rated Volt. |
No load | Load | Stall | |||||
| Current | Speed | Current | Speed | Torque |
Output power |
Torque | Current | ||
| V | mA | r/min | mA | r/min | gf.cm | W | gf.cm | mA | |
| JQM-050-006-9000 | 6 | ≤60 | 9000 | ≤260 | 7500 | 8 | 0.6 | ≥30 | ≥550 |
| JQM-050-006-12000 | 6 | ≤70 | 12000 | ≤300 | 9300 | 10 | 1.0 | ≥40 | ≥1000 |
| JQM-050-012-9000 | 12 | ≤30 | 9000 | ≤130 | 7500 | 8 | 0.6 | ≥30 | ≥300 |
| JQM-050-012-12000 | 12 | ≤50 | 12000 | ≤200 | 10000 | 10 | 1.0 | ≥40 | ≥600 |
Technical Data of Gearbox:
| Number of stages | 2 | 4 | 5 |
| Reduction ratio | 3,7,10 |
16,17,20,30 ,35,50,63,70,86 |
115,150, 210,250,360 |
| Gearbox length “L”mm | 11 | 11 | 11 |
| Breaking torque(kgf.cm) | 0.6 | 0.9 | 2 |
| Gearbox efficiency | 81% | 65% | 59% |
Gear Motor Mechanical Size:
What a Model Number Tells You?
We follow some rules to create each model number. A model number would tell you a lot of useful messages. Here is a sample.
So here we can learn that it is a 37mm Round Spur gear motor, 12V driving motor #555, no load input speed 6000rpm and reduction ratio 100:1. Hey, what about output speed? You need to do a little calculation. Input speed 6000rpm ÷ reduction ratio 100 = 60rpm
Gear Motor Electric Data:
| Model Number | Rated Volt. | No Load | At Max Efficiency | Stall | |||||
| Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| rpm | mA | rpm | mA | gf.cm | W | mA | gf.cm | ||
| JQM-13SS0500038500-150K | 3V | 56 | 120 | 43 | 360 | 597 | 0.3 | 890 | 2183 |
| JQM-13SS0503.716000-360K | 3.7V | 44 | 220 | 26 | 850 | 2560 | 0.7 | 1360 | 5800 |
| JQM-13SS05000513000-150K | 5V | 70 | 80 | 55 | 280 | 620 | 0.3 | 740 | 2500 |
| JQM-13SS05000620000-63K | 6V | 317 | 260 | 230 | 700 | 600 | 1.4 | 1740 | 2400 |
| JQM-13SS05000630000-86K | 6V | 348 | 400 | 250 | 1400 | 850 | 2.2 | 3650 | 3600 |
| JQM-13SS05001216000-10K | 12V | 1600 | 100 | 1345 | 350 | 125 | 1.7 | 890 | 510 |
| JQM-13SS05001216000-35K | 12V | 457 | 100 | 370 | 350 | 403 | 1.5 | 1000 | 1720 |
| JQM-13SS05001216000-63K | 12V | 254 | 90 | 208 | 350 | 650 | 1.4 | 1000 | 2900 |
| JQM-13SS05001216000-86K | 12V | 186 | 100 | 160 | 400 | 800 | 1.3 | 1130 | 3400 |
| JQM-13SS05001210500-250K | 12V | 42 | 40 | 32 | 130 | 1280 | 0.4 | 300 | 4600 |
| JQM-13SS0500129000-360K | 12V | 25 | 35 | 20 | 100 | 1300 | 0.3 | 200 | 4640 |
| Remark: 1 gf.cm≈0.098 mN.m≈0.014 oz.in 1 mm≈0.039 in | |||||||||
Professional Factory:
Certificate Photos :
Packing:
Transportation:
Motor Application Fields:
FAQ:
Q:How long is the lead time of orders?
A:Lead time : 4 weeks after receive the deposit
Q:What is your trade Assurance?
A:100% product quality protection.
100% product on time shipment protection.
100% payment protection for your covered amount.
Q: What’s Moq?
A: 5PCS. Small Order Welcome.
Q:Do You Make Customized Product?
A:Yes,We Accpet IT.
Q:About After Sale Serive?
A: After Sales Services 24/7.
Q: What should I do if I'm not satisfied with your product?
A: If there are defects in its quality, we can exchange a good one for you.
Generally, this problem is rare.
Q:What is the payment term?
A:T/T and Paypal is used more,please contact us for details
Q:What is the quality level of your product?
A:We produce good quality, refuse to produce low quality.
Our motor products contain range:
