12V/24V 5W Electric Brushed DC Flat Metal Gear Motor JQM-95SS555 For Recreation Equipment

12V/24V 5W Electric Brushed DC Flat Metal Gear Motor JQM-95SS555 For Recreation Equipment

  • 12V/24V 5W Electric Brushed DC Flat Metal Gear Motor JQM-95SS555 For Recreation Equipment
  • 12V/24V 5W Electric Brushed DC Flat Metal Gear Motor JQM-95SS555 For Recreation Equipment
  • 12V/24V 5W Electric Brushed DC Flat Metal Gear Motor JQM-95SS555 For Recreation Equipment
  • 12V/24V 5W Electric Brushed DC Flat Metal Gear Motor JQM-95SS555 For Recreation Equipment
12V/24V 5W Electric Brushed DC Flat Metal Gear Motor JQM-95SS555 For Recreation Equipment
Product Details:
Place of Origin: China
Brand Name: Junqi
Certification: CE,ROHS, UL
Model Number: JQM-95SS555
Payment & Shipping Terms:
Minimum Order Quantity: 50pcs
Price: USD8-usd15/pc (Negotiable)
Packaging Details: suite for export
Delivery Time: as confirmed
Payment Terms: L/C, T/T, Western Union,PAYPAL
Supply Ability: 10000PCS/Month
Contact Now
Detailed Product Description
Product Name: DC Gear Motor Commutation: Brush
Model: JQM-95SS555 Voltage: 12~24VDC
Speed: 2.5~90RPM Power: 4~22W
Torque: 5~50kg.cm Construction: Permanent Magnet
Diameter: 95mm Application: BOAT, Car, Electric Bicycle, FAN, Home Appliance

12V/24V 5W Electric Brushed DC Flat Metal Gear Motor JQM-95SS555 For Recreation Equipment

12V/24V 5W Electric Brushed DC Flat Metal Gear Motor JQM-95SS555 For Recreation Equipment 0





Driving Motor Data:

Motor model Rated Volt. No load Load Stall
Current Speed Current Speed Torque power Torque Current
V mA rpm mA rpm gf.cm W gf.cm mA
JQM-5550066000 6 ≤858 6000 ≤2250 4500 300 13.8 ≥1080 ≥10000
JQM-5550123000 12 ≤171 3000 ≤561 2400 126 3.16 ≥560 ≥2390
JQM-5550126000 12 ≤350 6000 ≤2300 4500 280 13.19 ≥1000 ≥10230
JQM-5550128500 12 ≤638 8500 ≤2800 6450 300 20.3 ≥1120 ≥11900
JQM-5550243000 24 ≤120 3000 ≤336 2400 198 4.98 ≥990 ≥1430
JQM-5550244500 24 ≤174 4500 ≤620 3600 309 11.65 ≥1390 ≥3630
JQM-5550246000 24 ≤270 6000 ≤800 5370 420 23.6 ≥1000 ≥5820



Technical Data of Gearbox:

Reduction Stage 3 4 5
Reduction Ratio 94K 394K 1166K
Length of Gearbox "L" mm 16 16 16
Gearbox Efficiency 73% 65% 59%

1. Main voltage: 12VDC, 24VDC
2. Typical applications:Instrument, Electric tools,Coffee machine,Vending machine, Massager,Game machine,Electric window opener,Automation equipment
3. Square Gearbox size: 95*60*H16mm
4. Torque: 2~80kgf.cm
5. Direction: CW, CCW
6. Voltage, speed, and shaft can be customized based
7. Encoder 13PPR available



Gear Motor Mechanical Size:

12V/24V 5W Electric Brushed DC Flat Metal Gear Motor JQM-95SS555 For Recreation Equipment 1
Gear Motor Electric Data:

Model Number Rated Volt. No Load At Max Efficiency Stall
Speed Current Speed Current Torque Power Current Torque
rpm mA rpm mA Kgf.cm W mA Kgf.cm
JQM-95SS5550129500-36K 12V 264 ≤750 210 ≤3650 7.2 15.52 ≥10400 ≥30
JQM-95SS5550126000-394K 12V 15 ≤420 13 ≤1720 60 8.01 ≥7200 ≥355
JQM-95SS5550124500-394K 12V 11 ≤360 9 ≤1500 75 6.93 ≥4850 ≥350
JQM-95SS5550124500-624K 12V 7.2 ≤300 6.2 ≤1200 68 4.33 ≥3360 ≥300
JQM-95SS5550123000-394K 12V 7.6 ≤360 5.4 ≤1200 65 3.60 ≥3000 ≥220
JQM-95SS5550249000-66K 24V 136 ≤350 115 ≤2050 18.5 21.83 ≥8600 ≥108
JQM-95SS5550246000-36K 24V 167 ≤730 133 ≤2500 13.8 18.84 ≥4000 ≥38
JQM-95SS5550244500-540K 24V 8.3 ≤450 5.7 ≤1300 115 6.73 ≥3200 ≥450
Remark: 1 Kgf.cm≈0.098 N.m≈14 oz.in 1 mm≈0.039 in

Notes: Above is our standard models for your reference, we can make as customer request.





Professional Factory:

NEMA43 110*110m Brushless DC Motor1.4KW 60VDC(115VAC) 3000RPM  Max 4.5N.m TorqueBLDC DC motor 2





Certificate Photos :

NEMA43 110*110m Brushless DC Motor1.4KW 60VDC(115VAC) 3000RPM  Max 4.5N.m TorqueBLDC DC motor 3

Packing:

NEMA43 110*110m Brushless DC Motor1.4KW 60VDC(115VAC) 3000RPM  Max 4.5N.m TorqueBLDC DC motor 4

Transportation:

NEMA43 110*110m Brushless DC Motor1.4KW 60VDC(115VAC) 3000RPM  Max 4.5N.m TorqueBLDC DC motor 5

Motor Application Fields:


12V/24V 5W Electric Brushed DC Flat Metal Gear Motor JQM-95SS555 For Recreation Equipment 6



Our motor products contain range:

12V/24V 5W Electric Brushed DC Flat Metal Gear Motor JQM-95SS555 For Recreation Equipment 7



FAQ:



Q:How long is the lead time of orders?

A:Lead time : 4 weeks after receive the deposit



Q:What is your trade Assurance?

A:100% product quality protection.

100% product on time shipment protection.

100% payment protection for your covered amount.



Q: What’s Moq?

A: 5PCS. Small Order Welcome.



Q:Do You Make Customized Product?

A:Yes,We Accpet IT.



Q:About After Sale Serive?

A: After Sales Services 24/7.



Q: What should I do if I'm not satisfied with your product?

A: If there are defects in its quality, we can exchange a good one for you.

Generally, this problem is rare.



Q:What is the payment term?

A:T/T and Paypal is used more,please contact us for details



Q:What is the quality level of your product?

A:We produce good quality, refuse to produce low quality.
