| Place of Origin: | China |
| Brand Name: | Junqi |
| Certification: | CE,ROHS, UL |
| Model Number: | JQM-65SS3540 |
| Minimum Order Quantity: | 50pcs |
|---|---|
| Price: | USD6-usd10/pc (Negotiable) |
| Packaging Details: | suite for export |
| Delivery Time: | as confirmed |
| Payment Terms: | L/C, T/T, Western Union,PAYPAL |
| Supply Ability: | 10000PCS/Month |
| Product Name: | DC Gear Motor | Commutation: | Brush |
|---|---|---|---|
| Model: | JQM-65SS3540 | Voltage: | 3~24VDC |
| Speed: | 10~173RPM | Power: | 1~4.2W |
| Torque: | 1~20kg.cm | Construction: | Permanent Magnet |
| Diameter: | 65mm | Application: | BOAT, Car, Electric Bicycle, FAN, Home Appliance |
1. Main voltage: 3V, 6V, 12VDC, 24VDC
2. Typical applications: Automatic door-lock, projector, hairdressing equipment
3. Square Gearbox size: 65*38*H12mm
4. Torque: 1-20kgf.cm
5. Direction: CW, CCW
6. Voltage, speed, and shaft can be customized based
7. Encoder 13PPR available
Driving Motor Data:
| Motor model | Rated Volt. | No load | Load | Stall | |||||
| Current | Speed | Current | Speed | Torque | power | Torque | Current | ||
| V | mA | rpm | mA | rpm | gf.cm | W | gf.cm | mA | |
| JQM-35400124500 | 12 | ≤50 | 4500 | ≤420 | 3600 | 96 | 3.62 | ≥430 | ≥1790 |
| JQM-35400126000 | 12 | ≤59 | 6000 | ≤513 | 5100 | 100 | 5.34 | ≥600 | ≥2180 |
| JQM-35400244500 | 24 | ≤45 | 4500 | ≤215 | 3600 | 97 | 3.66 | ≥436 | ≥910 |
| JQM-35400247000 | 24 | ≤38 | 7000 | ≤411 | 5100 | 115 | 6.14 | ≥380 | ≥1750 |
Technical Data of Gearbox:
| Reduction Stage | 3 | 4 | 5 |
| Reduction Ratio | 40.5K, 67.5K | 135K, 225K | 450K |
| Length of Gearbox "L" mm | 12 | 12 | 12 |
| Gearbox Efficiency | 73% | 65% | 59% |
Gear Motor Mechanical Size:
Gear Motor Electric Data:
| Model Number | Rated Volt. | No Load | At Max Efficiency | Stall | |||||
| Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| rpm | mA | rpm | mA | Kgf.cm | W | mA | Kgf.cm | ||
| JQM-65SS35400128000-178K | 12V | 44 | ≤250 | 34 | ≤900 | 8.8 | 3.1 | ≥2500 | ≥42 |
| JQM-65SS35400246000-67.5K | 12V | 88 | ≤60 | 77 | ≤300 | 3.5 | 2.8 | ≥1000 | ≥22 |
| JQM-65SS35400126000-450K | 12V | 13 | ≤150 | 10.5 | ≤500 | 11 | 1.2 | ≥1650 | ≥72 |
| JQM-65SS35400123000-225K | 12V | 13.3 | ≤75 | 11 | ≤130 | 4.5 | 0.5 | ≥550 | ≥25 |
| JQM-65SS35400123000-450K | 12V | 6.5 | ≤70 | 5.2 | ≤250 | 12 | 0.6 | ≥600 | ≥60 |
| JQM-65SS35400247000-225K | 24V | 31 | ≤35 | 28 | ≤280 | 5.6 | 1.6 | ≥1300 | ≥43 |
| Remark: 1 Kgf.cm≈0.098 N.m≈14 oz.in 1 mm≈0.039 in | |||||||||
Notes: Above is our standard models for your reference, we can make as customer request.
