6V/12V/24V DC Gear Motor JQM-65SS3540 1~20kgf.cm , 10~173rpm Low Speed , High Torque For RC Toy Machine, Water Valve

6V/12V/24V DC Gear Motor JQM-65SS3540 1~20kgf.cm , 10~173rpm Low Speed , High Torque For RC Toy Machine, Water Valve

  • 6V/12V/24V  DC Gear Motor JQM-65SS3540  1~20kgf.cm , 10~173rpm Low Speed , High Torque For RC Toy Machine, Water Valve
  • 6V/12V/24V  DC Gear Motor JQM-65SS3540  1~20kgf.cm , 10~173rpm Low Speed , High Torque For RC Toy Machine, Water Valve
  • 6V/12V/24V  DC Gear Motor JQM-65SS3540  1~20kgf.cm , 10~173rpm Low Speed , High Torque For RC Toy Machine, Water Valve
  • 6V/12V/24V  DC Gear Motor JQM-65SS3540  1~20kgf.cm , 10~173rpm Low Speed , High Torque For RC Toy Machine, Water Valve
6V/12V/24V  DC Gear Motor JQM-65SS3540  1~20kgf.cm , 10~173rpm Low Speed , High Torque For RC Toy Machine, Water Valve
Product Details:
Place of Origin: China
Brand Name: Junqi
Certification: CE,ROHS, UL
Model Number: JQM-65SS3540
Payment & Shipping Terms:
Minimum Order Quantity: 50pcs
Price: USD6-usd10/pc (Negotiable)
Packaging Details: suite for export
Delivery Time: as confirmed
Payment Terms: L/C, T/T, Western Union,PAYPAL
Supply Ability: 10000PCS/Month
Contact Now
Detailed Product Description
Product Name: DC Gear Motor Commutation: Brush
Model: JQM-65SS3540 Voltage: 3~24VDC
Speed: 10~173RPM Power: 1~4.2W
Torque: 1~20kg.cm Construction: Permanent Magnet
Diameter: 65mm Application: BOAT, Car, Electric Bicycle, FAN, Home Appliance

6V/12V/24V DC Gear Motor JQM-65SS3540 1~20kgf.cm , 10~173rpm Low Speed , High Torque For RC Toy Machine, Water Valve

6V/12V/24V  DC Gear Motor JQM-65SS3540  1~20kgf.cm , 10~173rpm Low Speed , High Torque For RC Toy Machine, Water Valve 0

Gear Motor Mechanical Size:

6V/12V/24V  DC Gear Motor JQM-65SS3540  1~20kgf.cm , 10~173rpm Low Speed , High Torque For RC Toy Machine, Water Valve 1

1. Main voltage: 3V, 6V, 12VDC, 24VDC
2. Typical applications: Automatic door-lock, projector, hairdressing equipment
3. Square Gearbox size: 65*38*H12mm
4. Torque: 1-20kgf.cm
5. Direction: CW, CCW
6. Voltage, speed, and shaft can be customized based
7. Encoder 13PPR available

Driving Motor Data:

Motor model Rated Volt. No load Load Stall
Current Speed Current Speed Torque power Torque Current
V mA rpm mA rpm gf.cm W gf.cm mA
JQM-35400124500 12 ≤50 4500 ≤420 3600 96 3.62 ≥430 ≥1790
JQM-35400126000 12 ≤59 6000 ≤513 5100 100 5.34 ≥600 ≥2180
JQM-35400244500 24 ≤45 4500 ≤215 3600 97 3.66 ≥436 ≥910
JQM-35400247000 24 ≤38 7000 ≤411 5100 115 6.14 ≥380 ≥1750

Technical Data of Gearbox:

Reduction Stage 3 4 5
Reduction Ratio 40.5K, 67.5K 135K, 225K 450K
Length of Gearbox "L" mm 12 12 12
Gearbox Efficiency 73% 65% 59%



Gear Motor Electric Data:

Model Number Rated Volt. No Load At Max Efficiency Stall
Speed Current Speed Current Torque Power Current Torque
rpm mA rpm mA Kgf.cm W mA Kgf.cm
JQM-65SS35400128000-178K 12V 44 ≤250 34 ≤900 8.8 3.1 ≥2500 ≥42
JQM-65SS35400246000-67.5K 12V 88 ≤60 77 ≤300 3.5 2.8 ≥1000 ≥22
JQM-65SS35400126000-450K 12V 13 ≤150 10.5 ≤500 11 1.2 ≥1650 ≥72
JQM-65SS35400123000-225K 12V 13.3 ≤75 11 ≤130 4.5 0.5 ≥550 ≥25
JQM-65SS35400123000-450K 12V 6.5 ≤70 5.2 ≤250 12 0.6 ≥600 ≥60
JQM-65SS35400247000-225K 24V 31 ≤35 28 ≤280 5.6 1.6 ≥1300 ≥43
Remark: 1 Kgf.cm≈0.098 N.m≈14 oz.in 1 mm≈0.039 in

Notes: Above is our standard models for your reference, we can make as customer request.





Professional Factory:

NEMA43 110*110m Brushless DC Motor1.4KW 60VDC(115VAC) 3000RPM  Max 4.5N.m TorqueBLDC DC motor 2





Certificate Photos :

NEMA43 110*110m Brushless DC Motor1.4KW 60VDC(115VAC) 3000RPM  Max 4.5N.m TorqueBLDC DC motor 3

Packing:

NEMA43 110*110m Brushless DC Motor1.4KW 60VDC(115VAC) 3000RPM  Max 4.5N.m TorqueBLDC DC motor 4

Transportation:

NEMA43 110*110m Brushless DC Motor1.4KW 60VDC(115VAC) 3000RPM  Max 4.5N.m TorqueBLDC DC motor 5

Motor Application Fields:


6V/12V/24V  DC Gear Motor JQM-65SS3540  1~20kgf.cm , 10~173rpm Low Speed , High Torque For RC Toy Machine, Water Valve 6



Our motor products contain range:

6V/12V/24V  DC Gear Motor JQM-65SS3540  1~20kgf.cm , 10~173rpm Low Speed , High Torque For RC Toy Machine, Water Valve 7



FAQ:



Q:How long is the lead time of orders?

A:Lead time : 4 weeks after receive the deposit



Q:What is your trade Assurance?

A:100% product quality protection.

100% product on time shipment protection.

100% payment protection for your covered amount.



Q: What’s Moq?

A: 5PCS. Small Order Welcome.



Q:Do You Make Customized Product?

A:Yes,We Accpet IT.



Q:About After Sale Serive?

A: After Sales Services 24/7.



Q: What should I do if I'm not satisfied with your product?

A: If there are defects in its quality, we can exchange a good one for you.

Generally, this problem is rare.



Q:What is the payment term?

A:T/T and Paypal is used more,please contact us for details



Q:What is the quality level of your product?

A:We produce good quality, refuse to produce low quality.
