12V/24VDC 80W BLDC Coolant Electric Water Pump with PWM Control For Electric Van Thermal Management

Product Details:

Place of Origin:	China
Brand Name:	Junqi
Certification:	TS16949,CE, UL
Model Number:	JP80 Series Water Pump

Payment & Shipping Terms:

Minimum Order Quantity:	12pcs ( sample available)
Price:	negotiation
Packaging Details:	Suite for export
Delivery Time:	depend on the order quantity /Negotiable
Payment Terms:	T/T, , Western Union, Paypal
Supply Ability:	10000pcs per month

Contact Now

Detailed Product Description

Model:	JP80-12V/24V	Type:	Coolant Water Pump
Rated Voltage:	12V/24V	Outlet Size:	20mm
Power:	80W	Warranty:	12 Months
Motor:	BLDC Motor	Brand:	JEUNKEI
Highlight:	Electric Window Regulator 81286016143 , MAN TGA Electric Window Regulator , ISO14001 Window Regulator Motor

12V/24VDC 80W BLDC Coolant Electric Water Pump with PWM Control For Electric Van Thermal Management

Technical Parameter:

1. Rated Voltage: DC12V/24V

2. Rated Current: 6.7A/ 3.3A

3. Operating Voltage: DC9~16V/ DC 18~32V

4. Rated Power: 80W

5. Workign environment: -40℃~105℃

6. Working Medium: 50% glcol aqueous solution

7. Protection level: IP67

8. Working Noise: ≤45dB ( Distance 1m)

9. Working life: ≥20000h

10. Weight: 0.8kg

Working Performance Curve:

12V/24VDC 80W BLDC Coolant Electric Water Pump with PWM Control For Electric Van Thermal Management 0

Application:

JUNQI BLDC Electric Water Pump widely using for EV motor cooling, EV motor controller cooling, Turbocharger intercooler pump, EV battery thermal management, Battery energy storage cooling, Fuel cell cooling, large-scale GPU cooling, Industrial cooling system, Immersion cooling, Communication base station cooling, Supercomputer cooling

12V/24VDC 80W BLDC Coolant Electric Water Pump with PWM Control For Electric Van Thermal Management 1

Test Capability:

12V/24VDC 80W BLDC Coolant Electric Water Pump with PWM Control For Electric Van Thermal Management 2

Dimensions(mm):

For more pump details please contact with us via email: ivanzhu@junqitrading.com
