55W 24V Water Pump 22L/min Brushless mini Booster Pump 1.5A 11m for Chiller Machine and LED Light Pump

55W 24V Water Pump 22L/min Brushless mini Booster Pump 1.5A 11m for Chiller Machine and LED Light Pump

  • 55W 24V Water Pump 22L/min Brushless mini Booster Pump 1.5A 11m for Chiller Machine and LED Light Pump
  • 55W 24V Water Pump 22L/min Brushless mini Booster Pump 1.5A 11m for Chiller Machine and LED Light Pump
  • 55W 24V Water Pump 22L/min Brushless mini Booster Pump 1.5A 11m for Chiller Machine and LED Light Pump
  • 55W 24V Water Pump 22L/min Brushless mini Booster Pump 1.5A 11m for Chiller Machine and LED Light Pump
  • 55W 24V Water Pump 22L/min Brushless mini Booster Pump 1.5A 11m for Chiller Machine and LED Light Pump
55W 24V Water Pump 22L/min Brushless mini Booster Pump 1.5A 11m for Chiller Machine and LED Light Pump
Product Details:
Place of Origin: China
Brand Name: junqi
Certification: IS9001, TS16949,CE
Model Number: JQ-P6202-2Pin
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: USD23.81/PC Ex-works
Packaging Details: suitable for export
Delivery Time: base on order,
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 1000set/month
Contact Now
Detailed Product Description
Model: JQ-P6202-2Pin Material: PPS+GF,
Voltage: 24V Power: 55w
Max Flow Rate: 22L/min Head: 11m
Application: Laser Equipment Water-cooling
Highlight:

20L/Min General Electric Water Pump

,

12V General Electric Water Pump

,

Car Auxiliary Heaters Electric Water Pump

55W 24V Water Pump 22L/min Brushless mini Booster Pump 1.5A 11m for Chiller Machine and LED Light Pump

Application:



1. solar heater circular water system
2. Intelligent toilet core
3. laser equipment water-cooling
4. water heating Mattress
5. water circulation system
6. beer machine




Features:
Centrifugal pump
◆Magnetic force transmission (shield pump structure)
◆High efficiency brushless DC motor, low power consumption, high efficiency,
long service life.
◆With wide range operating temperature
◆PWM signal speed controlling
◆With constant flow controlling
◆Reverse polarity protection (optional)
◆Dry running protection (optional)
◆Over Voltage, over current protection
◆Overload, over temperature protection





Technical Parameters Table:


Model:JQ-P6202
Voltage:DC24V
Power:55W
Current:1.5A
Transmission medium: Hot water pump
Pump shaft position : Horizontal
Drive mode: Electromagnetic
Impeller Intake: Single Suction
Material:Engineering plastics
Color:Black&Yellow
Size:118mm*80mm
Maximum lift:11meters
Maximum flow:22L/min




2. Mechanical Dimensions:



55W 24V Water Pump 22L/min Brushless mini Booster Pump 1.5A 11m for Chiller Machine and LED Light Pump 0









Details:

55W 24V Water Pump 22L/min Brushless mini Booster Pump 1.5A 11m for Chiller Machine and LED Light Pump 1

Tag:

100W BLDC Water Pump,

24VDC Brushless DC Motor Water Pump,

300w Brushless DC Motor Water Pump
