To Create Value For Customers. Integrity and Win-Win.
 |
| Place of Origin: | China |
| Brand Name: | junqi |
| Certification: | IS9001, TS16949,CE |
| Model Number: | JP-BL43-250K |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD230.78/PC - USD200 |
| Packaging Details: | suitable for export |
| Delivery Time: | base on order, |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 1000set/month |
| Model: | JP-BL43-250K | Material: | PPS+GF, Stainless |
|---|---|---|---|
| Voltage: | 24VDC ( 18V-32VDC) | Power: | 310W |
| Rated Flow Rate: | 3000L/H | Head: | 18M |
| Application: | Hybrid Bus, Electric Vehicles, Electric Trucks | ||
| High Light: | 18m Brushless DC Water Pump,310W Brushless DC Water Pump,Trucks BLDC Water Pump |
||
■ Applications
Widely used in hybrid bus, hybrid passenger car, electric vehicles, LongHaul Trucks, Electric Drayage Truck, Logistics and Freightliner Electric Trucks, and other heating and cooling circulation system.
■ Features
◆ Centrifugal pump
◆ Magnetic force transmission
◆ High efficiency brushless DC motor, low power consumption, high efficiency, long service life.
◆ With wide range operating temperature
◆ PWM signal speed controlling
◆ Diagnostic signal output
◆ With constant flow controlling
◆ Reverse polarity protection
◆ Dry running protection
◆ Over Voltage, over current protection
◆ Overload, over temperature protection
■Technical parameter
| Model | JP-BL43-250K |
| Rated Voltage (VDC) | 24VDC |
| Working Voltage Range | 18V~32VDC |
| Flow Rate/Head | When Flow=3000L/h, H=18m |
| Rated Power | 310W |
| Service Life | more than 20000h |
| Protection Level | IP68 |
| Noise | ≤60dB(A) |
| Weight | 1950g (wihout bracket) |
Connector model and the corresponding electrical properties (see figure 3):
| AMP282104-1 | 1 | 2 |
| 24v (Red) | GND(Black) |
Figure 3
■ Attentions
1. Working ambient temperature:-40℃--120℃, should try to avoid close to three-element catalytic, gas discharge pipe system and engine during the installation, ensure the working environment temperature.
2. The installation position of the water pump should as much as possible close to the low water level , to extend the service life of the pump.
4. Please use the pump far from the dusty environment, the dust is harmful to reduce the service life
5. Pay attention to the purity of the water, avoid to jam and impeller-blocked to reduce the service life of pump
■ Performance parameter
■External dimension
