Brushless DC Motor Driver IC JY21L SOP-8 Can instead IR2101S Push Chip For Small and Medium-power Motor Driver

Product Details:

Place of Origin:	China
Brand Name:	JEUNKEI
Certification:	ISO9001, CE
Model Number:	JY21L

Payment & Shipping Terms:

Minimum Order Quantity:	50pcs ( sample available)
Price:	USD0.5-USD0.9/PC
Packaging Details:	Suite for export
Delivery Time:	depend on the order quantity /Negotiable
Payment Terms:	T/T, , Western Union, Paypal
Supply Ability:	10000pcs per month

Contact Now

Detailed Product Description

Name:	Control IC	Model No.:	JY21L
Install Type:	Surface Mountable	Packaging Specifications:	SOP-8
Gate Drive Supply Range:	5.5v~20V	Output Source/Sink Current Capability:	450mA/850mA
High Side Floating Supply:	-0.3~150V	Low Side And Main Power Supply:	-0.3~25V
Highlight:	Control Brushless DC Motor Driver IC , SOP-8 Brushless DC Motor Driver IC , Brushless DC Motor Driver IC

General Description
The product is a high voltage, high speed power MOSFET and IGBT driver based on P-SUB P-EPI process. The floating channel driver can be used to drive two N-channel power MOSFET or IGBT independently which operates up to 150V. Logic inputs are compatible with standard CMOS or LSTTL output, down to 3.3V logic. The output drivers feature a high pulse current buffer stage designed for minimum driver cross conduction. Propagation delays are matched to simplify use in high frequency applications.

Features:
● 3.3V logic compatible
● Fully operational to +150V
● Floating channel designed for bootstrap operation
● Gate drive supply range from 5.5V to 20V
● Output Source/Sink current capability 450mA/850mA
● Independent Logic input to accommodate all topologies
● -5V negative Vs ability
● Matched propagation delay for both channels

Applications
● Power MOSFET or IGBT driver
● Small and medium-power motor driver

Packages and Application Circuit:

Pin Description:

Pin Number	Pin Name	Pin Function
1	Vcc	Low side and main power supply
2	HIN	Logic input for high side gate driver output(HO)
3	LIN	Logic input for low side gate drvier output(LO)
4	COM	Ground
5	LO	Low side gate drive output, in phase with LIN
6	Vs	High side floating supply teturn or bootstrap return
7	HO	High side gate drive output, in phase with HIN
8	VB	High side floating supply

Functional Block Diagram:

Absolute Maximum Ratings:

Symbol	Definition	MIN.	MAX.	Units
VB	High side floating supply	-0.3	150	V
VS	High side floating supply return	VB-20	VB+0.3
VHO	High side gate drive output	VS-0.3	VB+0.3
VCC	Low side and main power supply	-0.3	25
VLO	Low side gate drive output	-0.3	VCC+0.3
VIN	Logic input of HIN&LIN	-0.3	VCC+0.3
ESD	HBM Model	2500	V
Machine Model	200	V
PD	Package Power Dissipation @TA≤25ºC	—	0.63	W
RthJA	Thermal Resistance Junction to Ambient	—	200	ºC/W
TJ	Junction Temperature	—	150	ºC
TS	Storage Temperature	-55	150
TL	Lead Temperature	—	300
