24V Mini CAPA Bipap Exhaust Blower BLDC Industrial Centrifugal Turbo Water proof Blower Fan

Product Details:

Place of Origin:	China
Brand Name:	Junqi
Certification:	ISO9001, ISO14001,CE,
Model Number:	OWB8570-24V

Payment & Shipping Terms:

Minimum Order Quantity:	2pcs ( sample available)
Price:	negotiation
Packaging Details:	Suite for export
Delivery Time:	depend on the order quantity /Negotiable
Payment Terms:	T/T, , Western Union, Paypal
Supply Ability:	10000pcs per month

Contact Now

Detailed Product Description

Model:	OWB8570-24V	Voltage:	24VDC
Max. Airflow:	49m³/h	Max. Airpressure:	15.0kpa
Material:	Plastic, Aluminum	Bearing:	NMB Ball Bearing
Fan Type:	DC Centrifugan Fan	Motor:	3-Phase Brushless Motor
Highlight:	24 volt brushless dc blower , water proof brushless dc blower , water proof 24v brushless blower

24V Mini CAPA Bipap Exhaust Blower, BLDC Industrial Centrifugal Turbo Water-proof Blower Fan

Prodcut Details:

Product Name	BLDC Blower
Model	OWB8570-24V
Voltage	24VDC
Current Level	3.0A/ 8.8A
Life time (MTTF)	＞15000 hours
Bearing	NMB Ball Bearing
Protect class	Water-proof
Driver board	External
Speed control	PWM or 0~5V
Weight	500g

Dimensions:

Overall size(L*W*H):89*83*70mm
Air inlet:φ16.8mm
Air outlet:φ16mm
Line's length:300mm

24V Mini CAPA Bipap Exhaust Blower BLDC Industrial Centrifugal Turbo Water proof Blower Fan 0

Wiring Diagram:

24V Mini CAPA Bipap Exhaust Blower BLDC Industrial Centrifugal Turbo Water proof Blower Fan 1

Notes:

1. Don't use max pressure and working point, this point is not safe since airflow is too small.

2. To add a filter onto the inlet can make the blower run longer time

3. The right impeller fun direction is CCW.

Performance:

OWB8570-24V Blower can reach maximum 47m³/h airflow at 0kpa pressure and maximum 15kpa static pressure. Other load point preformance refere to below P-Q Curve.

24V Mini CAPA Bipap Exhaust Blower BLDC Industrial Centrifugal Turbo Water proof Blower Fan 2

Application:

24V Mini CAPA Bipap Exhaust Blower BLDC Industrial Centrifugal Turbo Water proof Blower Fan 3

Certificate:

24V Mini CAPA Bipap Exhaust Blower BLDC Industrial Centrifugal Turbo Water proof Blower Fan 4

FAQ:

Q1:Can you design a new blower fan if we give you target performance?
A:Yes, we offer ODM service for both blower fan and controller board

Q2:Can we connect this centrifugal air blower directly onto power source?
A:This blower fan is with BLDC motor inside and it needs a controller board to run.

Q3:What kind of power source shall we use to drive this blower fan?
A:Generally, our customers use 24vdc switching power supply or Li-on battery.

Q4:How to change impeller speed if we use your controller board?
A:You can use 0~5v or PWM to change speed. Our standard controller board is also with a potentiometer to change speed conveniently.

Q5: Can we use this centrifugal air blower to suct water?
A:This blower fan can not be used to suck dust directly.If you need to suck dust, you can ask us to choose proper item for this special working condition.

Q6: What can do if the working condition is dirty?
A:A filter is strongly recommended to assemble onto the the inlet of the blower fan.

Q7: How to decrease the noise of the blower?
A:Many of our customers use foam, silicone to fill between blower fan and machine to insulate the blower noise.
