| Place of Origin: | China |
| Certification: | CE,ROHS, UL |
| Model Number: | OW20ZYJ DC Gear motor |
| Minimum Order Quantity: | 50pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | suite for export |
| Delivery Time: | as confirmed |
| Payment Terms: | L/C, T/T, Western Union,PAYPAL |
| Supply Ability: | 10000PCS/Month |
| Product Name: | DC Gear Motor | Temperature Rise: | 40K |
|---|---|---|---|
| Environment Temperature: | -20℃~+80℃ | Insulation Resistance: | 100MΩ Min 500VDC |
| Rated Voltage: | 6~24v | Rated Power: | 0.06~9.6w |
| Rated Speed: | 3000~10000rpm | 3c Rated Voltage Range: | Less Than 36VDC |
| Efficiency: | 80% |
Features:
OW20ZYJ DC gear motor has the characteristics of simple structure, low noise, constant speed and long service life
Gernoral Specification:
Temperature rising: 40K
Environment temperature: -20℃~+80℃
Insulation resistance: 100MΩ min 500VDC
Insulation voltage: 500VAC for 1min
Insulation level: E
| Model specification | OW20ZYJ | ||
| Use voltage | DC/V | 3V-12 | |
| Reduction ratio | 1/37 | 1/58 | |
| No-load speed | rpm | 210 | 135 |
| No-load current | mA | 40 | 40 |
| Output torque | g.cm | 250 | 400 |
| Load speed | rpm | 180 | 110 |
| Load current | mA | 90 | 90 |
| Power | W | 1.5-3 | |
| Running direction | Bidirectional reversible | ||
Drawing :
Applications:
The motor widly using on Advertising exhibition equipment, medical equipment, stabilizing voltage power supply, towel machine, photographic equipment and automatic control instrument and other fields.
